TO ENTER SERVICE MODE
- Press and hold the “Menu” button on the TV.
- Then press the “Menu”, “8”, “Select” buttons on the remote control.
- Service menu screen will be displayed.
- To exit, press the “Menu” button on the TV set or the “Exit” button on the remote control.
- Hold down TV button on the remote control.
- Press “Menu” button.
- Press the “Information” button.
- Release the “TV” button.
- Remote control key functions, when in DCAM mode.
- Input => Blue [13*9] adjust
- Aspect => ROM Write.
- Day.Night => ROM read.
- Menu => Remove color
- Exit => Cross Hatch/Video Mode.
- Info => Green
- Guide + Calculation
- 2 => Cursor Up
- 5 => Cursor Down
- 6 =>Cursor Right
- 4 => Cursor Left
- 0 => Red [7*5] Adjust
- Stop => Initialize
- Play => Raster Position
- Fast Forward => Phase
- Press& Hold the TV button
- Press the [0] button.
- Press the [1] button.
- Release the TV button.
